Ignition Coil 398811 395326 395492 for Briggs & Stratton 7-16HP Engines

Replacement electronic ignition coil / magneto armature for select Briggs & Stratton 7–16 HP horizontal and vertical shaft single-cylinder engines used on Toro, Cub Cadet, Simplicity, Murray, MTD, Lawn-Boy, AYP / Electrolux, John Deere and other compatible outdoor power equipment.

Reference Part Numbers

• Briggs & Stratton 398811

• Briggs & Stratton 398265

• Briggs & Stratton 395326

• Briggs & Stratton 395492

• Briggs & Stratton 393993

• Briggs & Stratton 394963

• Briggs & Stratton 490748

• Briggs & Stratton 493237

• Briggs & Stratton 590454

• Briggs & Stratton 692605

• Briggs & Stratton 790817

• Briggs & Stratton 799381

• Briggs & Stratton 802574

• John Deere PT15339

• John Deere LG398811
• Oregon 33-344

Fits Select Briggs & Stratton Engines

• 17 Series: 170401, 170402, 170403, 170407, 170412, 170417, 170431, 170432, 170435, 170437, 170452, 170457, 170701, 170702, 170707, 171431, 171432, 171437, 171452, 171457, 176432, 176437, 176452

• 19 Series: 190401, 190402, 190403, 190406, 190407, 190412, 190415, 190416, 190417, 190431, 190432, 190435, 190436, 190437, 190451, 190452, 190457, 190492, 190493, 190496, 190497, 190701, 190702, 190705, 190706, 190707, 191700, 191702, 191703, 191705, 191706, 191707, 192402, 192407, 192412, 192417, 192432, 192436, 192437, 192452, 192701, 192702, 192705, 192707, 193701, 193702, 193705, 193706, 193707, 194402, 194412, 194415, 194417, 194702, 194706, 194707, 195412, 195415, 195422, 195423, 195431, 195432, 195433, 195435, 195436, 195437, 195451, 195452, 195456, 195457, 195702, 195703, 195706, 195707, 196402, 196412, 196417, 196422, 196427, 196432, 196436, 196437, 196452, 196457, 196702, 196706, 196707, 197402, 197412, 197415, 197417, 197702, 197707, 198702, 198707

• 19E / 19F / 19G / 19K Series: 19E400, 19E412, 19E416, 19E417, 19F400, 19F412, 19F432, 19F436, 19F437, 19G400, 19G402, 19G412, 19G415, 19G417, 19G432, 19G437, 19K400, 19K432, 19K437

• 22 Series: 220702, 220705, 220706, 220707, 221431, 221432, 221433, 221435, 221436, 221437, 221452, 221457, 222412, 222413, 222416, 222417, 222496, 226432, 226437, 226452, 226457

• 23–25 Series: 233411, 233431, 233432, 233451, 233452, 233461, 243431, 243432, 243434, 243436, 243437, 243451, 243452, 243457, 250412, 250417, 252411, 252412, 252413, 252415, 252416, 252417, 252702, 252707, 253412, 253417, 253702, 253703, 253706, 253707, 254412, 254415, 254416, 254417, 254421, 254422, 254425, 254426, 254427, 254702, 254707

• 25–32 Series: 255426, 255427, 256412, 256417, 256422, 256426, 256427, 256452, 256457, 256702, 256705, 256707, 257412, 257417, 257702, 257705, 257707, 258702, 258707, 259702, 259707, 280702, 280707, 281702, 281706, 281707, 326431, 326432, 326434, 326435, 326436, 326437, 32K437

Fits Select Toro Snow Blowers

• Toro 38090


• Toro 38160 – 1984 through 1987 applications

• Toro 38580 – 1988 through 1995 applications

• Select Toro snow blowers equipped with compatible Briggs & Stratton engines

Fits Select Cub Cadet Lawn & Garden Equipment

• Cub Cadet 0350039U

• Cub Cadet 0350040U

• Cub Cadet 1027

• Cub Cadet 1105

• Cub Cadet 1106

• Cub Cadet 130-200-100

• Select additional Cub Cadet lawn mowers and lawn tractors equipped with compatible Briggs & Stratton engines

Fits Select AYP / Electrolux Lawn Tractors

• Electrolux / AYP RL 1036 AR – Briggs & Stratton 10 HP engine application

• Select American Yard Products / Electrolux lawn tractors equipped with compatible Briggs & Stratton single-cylinder engines

Fits Select Simplicity Equipment

• Simplicity 1321PP
• Simplicity 1321PPE
• Select Simplicity lawn and garden equipment equipped with compatible Briggs & Stratton engines using 398811 ignition armature

Fits Select Murray Equipment

• Select Murray lawn tractors

• Select Murray riding lawn mowers

• Select Murray outdoor power equipment equipped with compatible Briggs & Stratton 7–16 HP single-cylinder engines

Fits Select MTD Equipment

• Select MTD riding lawn mowers equipped with compatible Briggs & Stratton 220707 engines
• Select MTD lawn and garden equipment using MTD BS-398811 / Briggs & Stratton 398811 ignition armatures

Fits Select Lawn-Boy Equipment

• Select Lawn-Boy outdoor power equipment equipped with compatible Briggs & Stratton engines using 398811 ignition armature

Fits Select John Deere Equipment

• John Deere S80
• John Deere S82
• John Deere S92
• Select John Deere equipment using PT15339 / LG398811 ignition armatures

Also Fits Select Applications

• Snow blowers / snow throwers

• Lawn tractors

• Riding lawn mowers

• Garden tractors

• Tillers

• Generators

• Chippers and shredders

• Other outdoor power equipment powered by compatible Briggs & Stratton single-cylinder engines

Specifications

• Type: Electronic Ignition Coil / Magneto Armature

• Ignition Type: Solid-State Electronic

• Engine Range: Select 7–16 HP engines

• Engine Configuration: Single Cylinder

• Shaft Applications: Horizontal and Vertical

• Mounting Hole Spacing: Approx. 64 mm

• Spark plug lead included

Package Includes

• 1 × replacement ignition coil / magneto armature

Designed to generate the high voltage required by the spark plug on compatible Briggs & Stratton single-cylinder engines.

The 398811 electronic armature can also be used on select older Briggs & Stratton engines to replace an original breaker-point ignition armature and convert the ignition system to solid-state electronic ignition.

This is an aftermarket replacement part.

Important Fitment Information

Briggs & Stratton used different ignition armatures across engines with similar horsepower ratings. This ignition coil is intended for select compatible engines using Briggs & Stratton 398811 and related replacement numbers listed above.

Engine horsepower alone does not confirm compatibility.

For older breaker-point applications, verify that 398811 is the specified solid-state replacement for your particular engine before converting the ignition system.

Please verify your original part number and complete Briggs & Stratton engine Model, Type and Code before ordering.
